Product Details:
|
| Applicable Industries: | Hotels, Building Material Shops, Machinery Repair Shops, Food & Beverage Factory | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Stainless Steel | Condition: | New |
| Power: | 800 | Weight: | 3 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Filter Type: | External Oil Filter | Application: | Hydraulic Oil Filters |
| MatGlass Fibererial: | Stainless Steel | Function: | Clean Hydraulic Oil |
| MOQ: | 1pcs | Structure: | Cartridge Filter |
| OEM: | Available | Service Life: | 2000h |
| Performance: | Efficient Filtration |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: ** | (A) Outer Diameter, Top: ** IN | HANDLE:NONE | |
Beta Rating: B15=200 | (B) Outer Diameter, Bottom:** IN | Seal Material: VITON | |
Collapse Pressure Rating: 3000 PSI | (C) INNER DIAMETER, TOP:** IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8 IN ** | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: 304 SS WIRE | ||
Filter Area: SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
