Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 0.4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.4 | Area Of Application:: | Hydraulics |
| Max Differential Pressure [bar]:: | Ulics Max. Permissible Differential Pressure [bar]: | Filter Medium:: | Glass Fiber |
| Filter Fineness [um(c)]:: | B12=1000 | Permitted Continuous Use Temperature:: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:25.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:2.00 IN (50.80 MM) | Handle: NONE | |
Beta Rating: B25 = 200 | (B) OUTER DIAMETER,BOTTOM:2.00 IN (50.80 MM) | Seal Material:BUNA-N | |
Collapse Pressure Rating:150 PSID | (C) INNER DIAMETER, TOP:1.00 IN (25.40 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) INNER DIAMETER, BOTTOM: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:8.25 IN (0.00 MM) | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
