Product Details:
|
| Applicable Industries: | Hotels, Building Material Shops, Machinery Repair Shops, Food & Beverage Factory | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 0.22 Kg |
| Dimension(L*W*H): | 44.5*22.1*157 | Warranty: | 1 Year |
| Weight [kg]: | 0.22 | Area Of Application: | Hydraulics |
| Max.differential Pressure [bar]: | 21 | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B12=1000 | Gaskets - Material: | NBR |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 12.00 ABSOLUTE | (A) Outer Diameter, Top: 1.75IN | HANDLE:NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:1.75IN | Seal Material: VITON | |
Collapse Pressure Rating: | (C) INNER DIAMETER, TOP:0.87IN | Type of Adhesive: | |
MAXIMUM TEMPERATURE: | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:6.20IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING: ZINC PLATING | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
