Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 10.00 ABSOLUTE | (A) Outer Diameter, Top:4.50 IN (114.30 MM) | HANDLE:NONE | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom:3.75 IN (95.25 MM) | Seal Material: BUNA | |
Collapse Pressure Rating: 100PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:0 PSID | (E) Length:20.00 IN (0.00 MM) (F) THREAD:N/A | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: N/A | |||
PLATING: N/A | |||
Outer Jacket: YES - PERFORATED | |||
Configuration: SINGLE OPEN END | |||
