Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Weight: | 0.7 Kg | Dimension(L*W*H): | OEM |
| Warranty: | 1 Year | Weight [kg]: | 0.7 |
| Area Of Application: | Hydraulics | Filter Medium: | Glass Fiber |
| Max.differential Pressure [bar]: | 21 | Filter Fineness [um(c)]: | B12=1000 |
| Seals - Material: | NBR | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING: 10.00 NOMINAL | (A) Outer Diameter, Top: 3.10 IN | HANDLE:NONE | |
BETA RATING:B10=200 | (B) Outer Diameter, Bottom:3.10 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 450 PSID | (C) INNER DIAMETER, TOP:1.60 IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:9.84 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
FILTER AREA:N/A | |||
PLATING:ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
