Product Details:
|
Applicable Industries: | Hotels, Building Material Shops, Machinery Repair Shops, Food & Beverage Factory | Showroom Location: | None |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
Core Components: | Glassfiber | Condition: | New |
Weight: | 1 Kg | Dimension(L*W*H): | OEM |
Warranty: | 1 Year | Filter Type: | External Oil Filter |
Application: | Hydraulic Oil Filters | MatGlass Fibererial: | Stainless Steel |
Function: | Clean Hydraulic Oil | MOQ: | 1pcs |
Structure: | Cartridge Filter | OEM: | Available |
Service Life: | 2000h | Performance: | Efficient Filtration |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING: 10.00 NOMINAL | (A) Outer Diameter, Top: 3.10 IN (78.74 MM) | HANDLE:NONE | |
BETA RATING:B10=200 | (B) Outer Diameter, Bottom:3.10 IN (78.74 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating: 450 PSID | (C) INNER DIAMETER, TOP:1.60 IN (40.64 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:9.84 IN (248 MM) | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
FILTER AREA:N/A | |||
PLATING:ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END |
