Product Details:
|
| Condition: | New | Applicable Industries: | Energy & Mining, Industrial Filtration |
|---|---|---|---|
| Weight (KG): | 2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Fiberglass | Warranty: | 1 Year |
| After Warranty Service: | Video Technical Support | Local Service Location: | None |
| After-sales Service Provided: | Online Support | Filter Type: | Hydraulic Filtration |
| Function: | Remove Impurities | Micron: | 10 |
| Material: | Glass Fiber Filter Material |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 10.00 ABSOLUTE | (A) Outer Diameter, Top: ** IN | Handle: YES | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom: ** IN | Seal Material: UREHTANE | |
Collapse Pressure Rating: 435 PSID | (C) Inner Diameter, Top: ** IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 250 F | (D) Inner Diameter, Bottom: | Type of Endcap: STEEL AND POLYAMIDE | |
Direction of Flow: OUTSIDE->IN | (E) Length: ** IN | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
FILTER AREA:4134 SQ.CM. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
