Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.4 | Area Of Application: | Hydraulics |
| Seals - Material: | NBR | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B12=1000 | Max.differential Pressure [bar]: | 21 |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 12.00 ABSOLUTE | (A) Outer Diameter, Top: 2.0IN | Handle: NONE | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom: 2.0IN | Seal Material: VITON | |
Collapse Pressure Rating: 150 PSI | (C) Inner Diameter, Top: 1.0 IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 250 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 8.25 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
