Product Details:
|
| Applicable Industries: | Hotels, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Printing Shops, Construction Works , Energy & Mining | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1.02 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Filter Type: | Oil Return Filter Element | Max.pressure [bar]:: | 10 |
| Filter Fineness [um(c)]:: | B10=1000 | Gasket Material:: | NBR |
| Permitted Continuous Use Temperature:: | -25°C To +120°C | MOQ: | 1pcs |
| Filter Medium:: | Glass Fiber | OEM: | Available |
| Service Life: | 2000h | Performance: | Efficient Filtration |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 10.00 ABSOLUTE | (A) Outer Diameter, Top: ** | HANDLE:NONE | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom:** | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) INNER DIAMETER, TOP:** | Type of Adhesive: | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:** | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: DOUBLE OPEN END | |||
