Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1,5 | Area Of Application:: | Hydraulics |
| Max. Will. Operating Pressure [bar]:: | 14 | Max. Will. Differential Pressure [bar]:: | 5 |
| Filter Fineness [μm(c)]: | B10=2 | Seals-material:: | NBR |
| Filter Medium:: | Cellulose |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 | (A) OUTER DIAMETER, TOP:5.06 IN (128.52 MM) | Handle: NONE | |
BETA RATING:N.A. | (B) OUTER DIAMETER, BOTTOM：5.06 IN (128.52 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:100 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20PSID | (E) LENGTH:11.00 IN (0.00 MM) (F) THREAD:1 1/2"-16 | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA: | ||
FILTER AREA:SQ.IN. | |||
PLATING：ELECTROTIN PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION: | |||
