Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 2.2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 2.2 | Gaskets - Material: | VITON |
| Area Of Application: | Hydraulics | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B4.5=1000 | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Max. Differential Pressure [bar]: | 21 | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:3.00ABSOLUTE | (A) Outer Diameter, Top:3.10IN | Handle:NONE | |
Beta Rating: B3=200 | (B) Outer Diameter, Bottom: 3.10IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150PSID | (C) Inner Diameter, Top:1.72IN | Type of Adhesive: EPOXY | |
Maximum Temperature:275F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:16.90IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: 1115SQ.IN. | |||
Plating:ZINC PALTED | |||
Outer Jacket: NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
