Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Area Of Application: | Hydraulics |
| Flow Direction: | Outside To Inside | Efficiency: | 12 μm At Beta 1000 |
| Outer Diameter [mm]: | 47,5 | Height [mm]: | 82,9 |
| Inner Diameter [mm]: | 22,2 | Filter Medium: | Synthetic |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:12.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:1.88 IN (47.75 MM) | HANDLE:NONE | |
BETA RATING:B12 = 200 | (B) OUTER DIAMETER, BOTTOM:1.88 IN (47.75 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:100 PSID | (C) INNER DIAMETER, TOP:0.86 IN (21.84 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:375 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) LENGTH:3.28 IN (0.00 MM) (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:60 SQ.IN. | |||
PLATING:60 SQ.IN. | |||
OUTER JACKET:NONE - NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
