Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 0.8 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.8 | Area Of Application: | Hydraulics |
| Max. Differential Pressure [bar]: | 10 | Filter Fineness [um(c)]: | B27=1000 |
| Bypass Valve Opening Pressure [bar]: | 1.7 | Filter Medium: | Glass Fiber |
| Gaskets - Material: | VITON | Permitted Continuous Use Temperature:: | -25°C To +120°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:25.00ABSOLUTE | (A) Outer Diameter, Top:2.75IN | Handle:NONE | |
Beta Rating: | (B) Outer Diameter, Bottom: 2.75IN | Seal Material: BUNA | |
Collapse Pressure Rating: 145PSID | (C) Inner Diameter, Top:1.56IN | Type of Adhesive: | |
Maximum Temperature:248F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8.38IN | Center Tube: | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: 210SQ.IN. | |||
Plating: | |||
Outer Jacket:NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
