Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 0.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.5 | Area Of Application: | Hydraulics |
| Flow Direction: | Outside In | Efficiency: | 8 Um At Beta 1000 |
| Filter Medium: | Synthetic | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:6.00ABSOLUTE | (A) Outer Diameter, Top:2.00IN | Handle:NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom: 2.00IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150PSID | (C) Inner Diameter, Top:1.00IN | Type of Adhesive: EPOXY | |
Maximum Temperature:250F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8.25IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 210SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
Contact Person: Mr.
