Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 2.4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 2.4 | Area Of Application: | Hydraulics |
| Gaskets - Material: | NBR | Max. Differential Pressure [bar]: | 21 |
| Filter Medium: | Glass Fiber | Filter Fineness [um(c)]: | B27=1000 |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:25.00ABSOLUTE | (A) Outer Diameter, Top:3.10IN | Handle:NONE | |
Beta Rating: B25=200 | (B) Outer Diameter, Bottom:3.10IN | Seal Material: BUNA-N | |
Collapse Pressure Rating:150PSID | (C) Inner Diameter, Top:1.72IN | Type of Adhesive: EPOXY | |
Maximum Temperature:250F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:16.90IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 1115SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket：NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
