Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 1.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1.5 | Area Of Application: | Hydraulics |
| Gaskets - Material: | NBR | Filter Fineness [um]: | B25=2 |
| Max. Differential Pressure [bar]: | 3 | Filter Medium: | Cellulose |
| Bypass Valve Opening Pressure [bar]: | 1.7 | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:25.00ABSOLUTE | (A) Outer Diameter, Top:5.12IN | Handle:NONE | |
Beta Rating: N/A | (B) Outer Diameter, Bottom:5.12IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) Inner Diameter, Top:2.56IN | Type of Adhesive: | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:7.87IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:PAPER | ||
Filter Area: 914SQ.IN. | |||
Plating: | |||
Outer Jacket:NONE | |||
Configuration:SINGLE OPEN END | |||
