Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.65 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.65 | Area Of Application: | Hydraulics |
| Max. Differential Pressure [bar]: | 10 | Bypass Valve Opening Pressure [bar]: | 1.7 |
| Filter Medium: | Wire Mesh | Gaskets - Material: | NBR |
| Mesh Size [um]: | 60 | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:60.00ABSOLUTE | (A) Outer Diameter, Top:3.90IN | Handle:NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:3.90IN | Seal Material: VITON | |
Collapse Pressure Rating:145PSI | (C) Inner Diameter, Top:1.60IN | Type of Adhesive: | |
Maximum Temperature:248F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8.43IN | Center Tube: | |
Get the quote by contacting us | Type of Media:304 SS WIRE | ||
Filter Area: 289SQ.IN. | |||
Plating: | |||
Outer Jacket:NONE | |||
Configuration:SINGLE OPEN END | |||
