Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Gaskets - Material: | NBR |
| Area Of Application: | Hydraulics | Flow Direction: | Outside To Inside |
| Filter Medium: | Glass Fiber | Filter Fineness [um(c)]: | B10=200 / B12=1000 |
| Permitted Continuous Use Temperature: | -30°C To +100°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:12.00ABSOLUTE | (A) Outer Diameter, Top:2.76 IN (70.10 MM) | Handle: NONE | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom: 2.76 IN (70.10 MM) | Seal Material: VITON | |
Collapse Pressure Rating: 450PSID | (C) Inner Diameter, Top: 1.33 IN (33.78 MM) | Type of Adhesive: EPOXY | |
Maximum Temperature:250F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) Length:4.50 IN (0.00 MM) (F) THREAD:NONE | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: 187 SQ.IN. | |||
Plating:ZINC PALTED | |||
Outer Jacket: NONE-NONE | |||
Configuration:SINGLE OPEN END | |||
