Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 2 | Area Of Application: | Hydraulics |
| Filter Fineness [um]: | B12=200 B15=1000 | Max. Differential Pressure [bar]: | 10 |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Seals-material: | NBR |
| Filter Medium: | Synthetic Polyester | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00ABSOLUTE | (A) Outer Diameter, Top:4.48 IN (113.79 MM) | Handle:NONE | |
Beta Rating:B10=200 | (B) Outer Diameter, Bottom:4.48 IN (113.79 MM) | Seal Material: BUNA-N | |
Collapse Pressure Rating:250 PSID | (C) Inner Diameter, Top:2.70 IN (68.58 MM) | Type of Adhesive: | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom:2.70 IN (68.58 MM) | Type of Endcap:STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:0 PSID | (E) Length:15.71 IN (68.58 MM) (F) THREAD:NONE | Center Tube:STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: | |||
Plating: | |||
Outer Jacket:NONE | |||
Configuration:DOUBLE OPEN ENDS | |||
