Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Gaskets - Material: | VITON |
| Filter Medium: | Glass Fiber | Bypass Valve Opening Pressure [bar]: | 1.7 |
| Area Of Application: | Hydraulics | Filter Fineness [um]: | B10=200 /B12=1000 |
| Max. Differential Pressure [bar]: | 10 | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Flow Direction: | Outside To Inside | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00ABSOLUTE | (A) Outer Diameter, Top:3.74IN | Handle:NONE | |
Beta Rating:B10=200 | (B) Outer Diameter, Bottom:3.74IN | Seal Material: BUNA-N | |
Collapse Pressure Rating:20 PSID | (C) Inner Diameter, Top:1.61IN | Type of Adhesive: EPOXY | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom:1.54IN | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:7.99IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: | |||
Outer Jacket:NONE | |||
Configuration:DOUBLE OPEN ENDS | |||
