Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Field Of Application: | Hydraulics |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:40.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.37 IN (85.60 MM) | HANDLE:NONE | |
BETA RATING: | (B) OUTER DIAMETER, BOTTOM:3.37 IN (85.60 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:350-PSID | (C) INNER DIAMETER, TOP:2.20 IN (55.88 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:2.20 IN (55.88 MM) | TYPE OF ENDCAP:STAINLESS STEEL | |
DIRECTION OF FLOW:OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:0 PSID | (E) LENGTH:4.93 IN (55.88 MM) (F) THREAD:NONE | CENTER TUBE:STAINLESS STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA: | |||
PLATING:N/A | |||
OUTER JACKET:NONE | |||
CONFIGURATION:DOUBLE OPEN END | |||
