Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 0.4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.4 | Area Of Application:: | Hydraulics |
| Gaskets - Material:: | NBR | Max Differential Pressure [bar]:: | 30 |
| Filter Medium:: | Glass Fiber | Filter Fineness [um(c)]:: | B10=200 / B12=1000 |
| Bypass Valve Opening Pressure [bar]:: | 3 | Permitted Continuous Use Temperature:: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) Outer Diameter, Top:2.75 IN (69.85 MM) | Handle: NONE | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom: 2.75 IN (69.85 MM) | Seal Material: VITON | |
Collapse Pressure Rating: 250 PSID | (C) INNER DIAMETER, TOP:1.25 IN (31.75 MM) | Type of Adhesive: | |
MAXIMUM TEMPERATURE: | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 5.75 IN (0.00 MM) | Center Tube: STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
