Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Area Of Application:: | Hydraulics |
| Max Differential Pressure [bar]:: | 30 | Filter Medium:: | Glass Fiber |
| Filter Fineness [um(c)]:: | B7=1000 | Gaskets - Material:: | NBR |
| Permitted Continuous Use Temperature:: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:5.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:3.63 IN | Handle: NONE | |
Beta Rating: | (B) Outer Diameter, Bottom: 3.63 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) INNER DIAMETER, TOP:1.89 IN | Type of Adhesive: | |
MAXIMUM TEMPERATURE: | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 10.00 IN | Center Tube: STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING:ZINC PLATED | |||
Outer Jacket: NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
