Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 1.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1.5 | Area Of Application:: | Hydraulics |
| Max Operating Pressure [bar]:: | 12 | Max Differential Pressure [bar]:: | 5 |
| Filter Medium:: | Glass Fiber | Filter Fineness [um(c)]:: | B12=1000 |
| Gaskets - Material:: | NBR |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:19.00 NOMINAL | (A) OUTER DIAMETER, TOP:5.06 IN (128.52 MM) | Handle: NONE | |
Beta Rating: N/A | (B) Outer Diameter, Bottom: 5.06 IN (128.52 MM) | Seal Material:BUNA | |
Collapse Pressure Rating: 75 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 10.75 IN (0.00 MM) | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING:ELECTROTIN PLATED | |||
Outer Jacket: YES - METAL | |||
CONFIGURATION:SINGLE OPEN END | |||
