Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Area Of Application:: | Oil Filtration |
| Connection Thread:: | 3/4-16 | Outside Diameter [mm]:: | 93 |
| Height [mm]:: | 136 | Filter Medium:: | Cellulose |
| Non-return Valve:: | NBR | Permitted Continuous Use Temperature:: | Yes |
| Seal - Outer Diameter [mm]:: | 71 | Gasket - Inner Diameter [mm]:: | 61 |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:20.00 NOMNAL | (A) OUTER DIAMETER, TOP:3.69 IN | Handle: NONE | |
Beta Rating: N/A | (B) OUTER DIAMETER, BOTTOM:3.69 IN | Seal Material:BUNA-N | |
Collapse Pressure Rating:75 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive: PLASTISOL | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER, BOTTOM: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 5.38 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: PAPER | ||
Filter Area: SQ.IN. | |||
PLATING:ELECTROTIN PLATED | |||
OUTER JACKET:YES - METAL | |||
CONFIGURATION:SINGLE OPEN END | |||
