Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight[kg]: | 0.5 | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:0.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:7.88 IN | Handle: NONE | |
Beta Rating: N/A | (B) OUTER DIAMETER, BOTTOM:7.88 IN | Seal Material:BUNA-N | |
Collapse Pressure Rating:75 PSID | (C) INNER DIAMETER, TOP:4.47 IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER, BOTTOM: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 5.47 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: WIRE MESH | ||
Filter Area: SQ.IN. | |||
PLATING:ELECTROTIN PLATED | |||
OUTER JACKET:NONE - NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
