Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 0.3 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.3 | Area Of Application:: | Hydraulics |
| Max Differential Pressure [bar]:: | 30 | Filter Medium:: | Glass Fiber |
| Filter Fineness [um(c)]:: | B12=1000 | Gaskets - Material:: | NBR |
| Permitted Continuous Use Temperature:: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 | (A) OUTER DIAMETER, TOP:2.17 IN (55.12 MM) | Handle: NONE | |
Beta Rating: BX=200 | (B) OUTER DIAMETER, BOTTOM:2.17 IN (55.12 MM) | Seal Material:BUNA | |
Collapse Pressure Rating:450 PSID | (C) INNER DIAMETER, TOP:0.99 IN (25.15 MM) | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER, BOTTOM: | Type of Endcap: STAINLESS STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 4.63 IN (0.00 MM) | Center Tube: STAINLESS STEEL | |
Get the quote by contacting us | Type of Media: FIBERGLASS | ||
Filter Area: SQ.IN. | |||
PLATING:STAINLESS STEEL | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
