Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.253 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.253 | Area Of Application:: | Oil Filtration |
| Bypass Valve Opening Pressure [bar]:: | 0.80 | Non-return Valve:: | Yes |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:25.00 NOMINAL | (A) OUTER DIAMETER, TOP:3.03 IN | Handle: NONE | |
Beta Rating:N/A | (B) OUTER DIAMETER,BOTTOM:3.03 IN | Seal Material:BUNA-N | |
Collapse Pressure Rating:75 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive:PLASTISOL | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER, BOTTOM: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:3.50 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media：PAPER | ||
Filter Area: SQ.IN. | |||
PLATING:ELECTROTIN PLATED | |||
OUTER JACKET:YES - METAL | |||
CONFIGURATION:SINGLE OPEN END | |||
