Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.8 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.8 | Area Of Application: | Hydraulics |
| Max.differential Pressure [bar]: | 30 | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B12=1000 | Seals - Material: | NBR |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:12.00 NOMINAL | (A) OUTER DIAMETER, TOP:3.63IN | Handle: YES | |
Beta Rating:B12=200 | (B) OUTER DIAMETER, BOTTOM:3.63IN | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:435 PSID | (C) INNER DIAMETER, TOP:1.88IN | Type of Adhesive:EPOXY | |
MAXIMUM TEMPERATURE:250F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:STEEL AND POLYAMIDE | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:7.57IN | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:4134 SQ.CM. | |||
PLATING:ZINA PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
