Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight[kg]:: | 4 | Outside Diameter [mm]:: | 332.4 |
| Gaskets - Material: | NBR | Filter Medium: | Cellulose |
| Inside Diameter [mm]:: | 172.3 | Height [mm]:: | 375 |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Filter Fineness [um(c)]: | B21=200 / B27=1000 |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:0.00 | (A) OUTER DIAMETER, TOP:13.13 IN (333.50 MM) | Handle: YES | |
BETA RATING:N/A | (B) OUTER DIAMETER, BOTTOM：12.90 IN (327.66 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:NOT RATED | (C) INNER DIAMETER, TOP:6.80 IN (172.72 MM) | Type of Adhesive：N/A | |
MAXIMUM TEMPERATURE:300 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:15.40 IN (0.00 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:PAPER | ||
FILTER AREA:N/A | |||
PLATING:N/A | |||
OUTER JACKET:YES | |||
CONFIGURATION:SINGLE OPEN END | |||
