Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 1 | Area Of Application:: | Oil Filtration |
| Seal - Outer Diameter [mm]:: | 110 | Height [mm]:: | 260 |
| Seal - Inner Diameter [mm]:: | 98 | Outside Diameter [mm]:: | 118 |
| Filter Medium:: | Cellulose | Connection Thread:: | 1 1/2-12 |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:25.00 NOMINAL | (A) OUTER DIAMETER, TOP:4.74 IN (120.40 MM) | Handle: NONE | |
BETA RATING:N/A | (B) OUTER DIAMETER, BOTTOM：4.74 IN (120.40 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:75 PSID | (C) INNER DIAMETER, TOP: | Type of Adhesive：PLASTISOL | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:URETHANE/METAL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:11.31 IN (0.00 MM) | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ELECTROTIN PLATED | |||
OUTER JACKET:YES - METAL | |||
CONFIGURATION:SINGLE OPEN END | |||
