Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company |
|---|---|---|---|
| Weight (KG): | 0.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.5 | Area Of Application:: | Hydraulics |
| Filter Medium:: | Wire Mesh | Gaskets - Material: | NBR |
| Max. Differential Pressure [bar]: | 21 | Mesh Size [um]: | 25 |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:25.00 | (A) OUTER DIAMETER, TOP:3.10IN | Handle: NONE | |
BETA RATING:B25=200 | (B) OUTER DIAMETER, BOTTOM：3.10IN | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:450PSID | (C) INNER DIAMETER, TOP:1.54IN | Type of Adhesive:EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:6.18IN | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:WIRE | ||
FILTER AREA:N/A | |||
PLATING:N/A | |||
OUTER JACKET：NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
