Product Details:
|
| Condition: | New | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 0.7 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.7 | Area Of Application: | Hydraulics |
| Max. Differential Pressure [bar]: | 210 | Filter Medium: | Glass Fiber |
| Filter Fineness [um(c)]: | B12=1000 | Gaskets - Material: | NBR |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00ABSOLUTE | (A) Outer Diameter, Top:2.36IN | Handle:NONE | |
Beta Rating:B12=200 | (B) Outer Diameter, Bottom:2.36IN | Seal Material: BUNA-N | |
Collapse Pressure Rating:3000PSID | (C) Inner Diameter, Top:1.39IN | Type of Adhesive: EPOXY | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom: | Type of Endcap:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:9.00IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: N/A | |||
Plating:ZINC PLATED | |||
Outer Jacket:NONE | |||
Configuration:SINGLE OPEN END | |||
