Product Details:
|
| Condition: | New | Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Area Of Application: | Hydraulics |
| Filter Medium: | Glass Fiber | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 1.00 ABSOLUTE | (A) Outer Diameter, Top: 1.83IN | Handle: NONE | |
Beta Rating:B1=200 | (B) Outer Diameter, Bottom: 1.83 IN | Seal Material: VITON | |
Collapse Pressure Rating:150PSID | (C) Inner Diameter, Top: 1.00IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 225F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 7.50IN | Center Tube: STEEL | |
Get the quote by contacting us | Type of Media: SYNTHETIC | ||
Filter Area: N/A | |||
Plating: N/A | |||
Outer Jacket: NONE | |||
Configuartion:SINGLE OPEN END | |||
