Product Details:
|
| Condition: | New | Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Construction Works , Energy & Mining, Other |
|---|---|---|---|
| Weight (KG): | 0.2 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.2 | Area Of Application: | Hydraulics |
| Filter Medium: | Glass Fiber | Gaskets - Material: | NBR |
| Max.differential Pressure [bar]: | 30 | Filter Fineness [um(c)]: | B21=200 |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 25.00 ABSOLUTE | (A) Outer Diameter, Top: 1.88IN | Handle: NONE | |
Beta Rating:B25=200 | (B) Outer Diameter, Bottom: 1.88 IN | Seal Material: VITON | |
Collapse Pressure Rating:100PSID | (C) Inner Diameter, Top: 0.88IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 225F | (D) Inner Diameter, Bottom:**IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 3.19IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE-NONE | |||
Configuartion:SINGLE OPEN END | |||
