Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1.42 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1.42 | Gaskets - Material: | NBR |
| Filter Medium: | Glass Fiber | Max. Differential Pressure [bar]: | 210 |
| Filter Fineness [um]: | 5 | Picture: | 6 |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 5.00 ABSOLUTE | (A) Outer Diameter, Top:3.07IN | Handle: NONE | |
Beta Rating: | (B) Outer Diameter, Bottom: 3.07IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) Inner Diameter, Top: 1.58N | Type of Adhesive: | |
Maximum Temperature: 212 F | (D) Inner Diameter, Bottom: IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 9.80IN | Center Tube: | |
Get the quote by contacting us | Type of Media: SYNTHETIC | ||
Filter Area: SQ.IN. | |||
Plating: | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
