Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.58 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.58 | Area Of Application: | Hydraulics |
| Flow Direction: | Outside In | Efficiency: | 12 Um At Beta 1000 |
| Filter Medium: | Synthetic | Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:25.00 ABSOLUTE | (A) Outer Diameter, Top: 3.09IN | Handle: NONE | |
Beta Rating:B25=200 | (B) Outer Diameter, Bottom: 3.09IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) Inner Diameter, Top: 1.66IN | Type of Adhesive: EPOXY | |
Maximum Temperature: | (D) Inner Diameter, Bottom:**IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 10.25IN | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: MICROGLASS | ||
Filter Area: | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE-NONE | |||
Configuration: SINGLE OPEN END | |||
