Product Details:
|
Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
---|---|---|---|
Weight (KG): | 4.6 | Showroom Location: | None |
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
Core Components: | Glass Fiber | Warranty: | 1 Year |
Weight [kg]: | 4.6 | Area Of Application: | Hydraulics |
Filter Medium: | Glass Fiber | Gaskets - Material: | NBR |
Max.differential Pressure [bar]: | 10 | Filter Fineness [um(c)]: | B10=200/B12=1000 |
Permitted Continuous Use Temperature: | -25°C To +120°C | Flow Direction: | Outside To Inside |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:6.00 ABSOLUTE | (A) Outer Diameter, Top:5.99IN | Handle: NONE | |
Beta Rating: B6=200 | (B) Outer Diameter, Bottom:5.99IN | Seal Material:BUNA-N | |
Collapse Pressure Rating: 150PSID | (C) Inner Diameter, Top:3.28IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 250F | (D) Inner Diameter, Bottom:3.28IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:25.56IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media:MICROGLASS | ||
Filter Area: 3927SQ.IN. | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE-NONE | |||
Configuration: DOUBLE OPEN END |
