Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Gaskets - Material: | NBR |
| Filter Medium: | Polyester | Area Of Application: | Hydraulics |
| Permitted Continuous Use Temperature: | -25°C To +120°C | Filter Fineness [um]: | 40 |
| Max.differential Pressure [bar]: | 5 |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 40.00 ABSOLUTE | (A) Outer Diameter, Top:3.68IN | Handle: NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:3.68IN | Seal Material: BUNA-A | |
Collapse Pressure Rating: | (C) Inner Diameter, Top:1.78IN | Type of Adhesive: | |
Maximum Temperature: | (D) Inner Diameter, Bottom:1.78IN | Type of Endcap:STEEL | |
Direction of Flow: INSIDE->OUT | (E) Length:9.31IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: SYNTHETIC | ||
Filter Area: SQ.IN. | |||
Plating: N/A | |||
Outer Jacket: YES | |||
Configuration: DOUBLE OPEN END | |||
