Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 1 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber, HV Glassfiber | Warranty: | 1 Year |
| Weight [kg]: | 1 | Area Of Application: | Hydraulics |
| Gaskets - Material: | VITON | Filter Medium: | Glass Fiber |
| Max.differential Pressure [bar]: | 21 | Filter Fineness [um(c)]: | B12=1000 |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 12.00 ABSOLUTE | (A) Outer Diameter, Top:2.75IN | Handle: NONE | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom:2.75IN | Seal Material: VITON | |
Collapse Pressure Rating: 150PSID | (C) Inner Diameter, Top:1.35IN | Type of Adhesive: EPOXY | |
Maximum Temperature:275F | (D) Inner Diameter, Bottom:IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:8.24IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating:ZINC PLATED | |||
Outer Jacket: NONE-NONE | |||
Configuration: SINGLE OPEN END | |||
