Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 0.26 Kg |
| Dimension(L*W*H): | Customer's Request | Warranty: | 1 Year |
| Weight [kg]: | 0.26 | Gaskets - Material: | VITON |
| Area Of Application: | Hydraulics | Max.differential Pressure [bar]: | 21 |
| Filter Medium: | Glass Fiber | Filter Fineness [um(c)]: | B12=1000 |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating:10.00 ABSOLUTE | (A) Outer Diameter, Top: 2.44IN | Handle: NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:2.44IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) Inner Diameter, Top:1.46IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 212F | (D) Inner Diameter, Bottom:**IN | Type of Endcap:PLASTIC | |
Direction of Flow: OUTSIDE->IN | (E) Length:4.95IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
Plating: | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
