Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 0.62 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 0.62 | Filter Medium:: | Glass Fiber |
| Gaskets - Material: | NBR | Area Of Application: | Hydraulics |
| Filter Fineness [um(c)]:: | B10=200/B12=1000 | Flow Direction: | Outside To Inside |
| Max.differential Pressure [bar]: | 20 | Bypass Valve Opening Pressure [bar]: | 3 |
| Permitted Continuous Use Temperature: | -30°C To +100°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 12.00 ABSOLUTE | (A) Outer Diameter, Top:2.36IN | HANDLE:NONE | |
Beta Rating: | (B) Outer Diameter, Bottom:2.36IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: | (C) INNER DIAMETER, TOP:1.33IN | Type of Adhesive: | |
MAXIMUM TEMPERATURE:225 F | (D) Inner Diameter, Bottom:**IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:11.59IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: | |||
PLATING: | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
