Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.3 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]: | 0.3 | Seals - Material: | NBR |
| Area Of Application: | Hydraulics | Max. Differential Pressure [bar]: | 21 |
| Filter Fineness [um(c)]: | B12=1000 | Permitted Continuous Use Temperature: | -25°C To +120°C |
| Filter Medium: | Glass Fiber |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 12.00 ABSOLUTE | (A) Outer Diameter, Top: 1.80IN | HANDLE:NONE | |
Beta Rating: B12=200 | (B) Outer Diameter, Bottom:1.80 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150PSID | (C) INNER DIAMETER, TOP:1.00 IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:250F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) LENGTH:8.20 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: SQ.IN. | |||
PLATING: ZINC PLATED | |||
Outer Jacket: NONE-NONE | |||
Configuration: SINGLE OPEN END | |||
