Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 1 | Application: | Hydraulics |
| SealsMaterial: | NBR | Filter Medium: | Glass Fiber |
| Filter Fineness [um]: | B5=200, B7=1000 | Max. Will. Differential Pressure [bar: | 16 |
| Bypass Valve Opening Pressure [bar]: | Dp 2 | Zul. Continuous Operating Temperature: | -30°C To +100°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 5.00 ABSOLUTE | (A) Outer Diameter, Top: 2.76IN | HANDLE:NONE | |
Beta Rating: B5=200 | (B) Outer Diameter, Bottom:2.76IN | Seal Material:VITON | |
Collapse Pressure Rating: 232PSID | (C) INNER DIAMETER, TOP:1.61IN | Type of Adhesive: EPOXY | |
MAXIMUM TEMPERATURE:250 F | (D) Inner Diameter, Bottom:** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:11.96IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area: 438SQ.IN. | |||
PLATING: N/A | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
