Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Showroom Location: | None |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Months |
| Core Components: | Glassfiber | Condition: | New |
| Power: | 800 | Weight: | 1 Kg |
| Dimension(L*W*H): | OEM | Warranty: | 1 Year |
| Weight [kg]: | 1 | Area Of Application: | Hydraulics |
| Seals-Material: | NBR | Filter Fineness [um]: | B27=1000 |
| Bypass Valve Opening Pressure [bar]: | 2.5 | Zul. Continuous Operating Temperature: | -25°C To +120°C |
| Filter Medium: | Glass Fibre |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 25.00 ABSOLUTE | (A) Outer Diameter, Top:2.50 IN | Handle: NONE | |
Beta Rating: B25=200 | (B) Outer Diameter, Bottom:2.50 IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 150 PSID | (C) Inner Diameter, Top:1.05 IN | Type of Adhesive: EPOXY | |
Maximum Temperature: 225F | (D) Inner Diameter, Bottom: | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:12.00 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area:N/A | |||
Plating: ZINC PLATED | |||
Outer Jacket: NONE | |||
Configuration: SINGLE OPEN END | |||
