Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 0.3 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 0.3 | Filter Medium:: | Glass Fibre |
| I.a. Suitable For Series:: | Hydraulics | Seals Material:: | NBR |
| Filter Fineness [μm(c)]:: | B12=1000 | Max. Differential Pressure [bar]:: | 10 |
| Zul. Continuous Operating Temperature:: | -25°C Bis +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:10.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:2.24 IN (56.90 MM) | Handle: NONE | |
BETA RATING:B10=200 | (B) OUTER DIAMETER, BOTTOM:2.24 IN (56.90 MM) | Seal Material:BUNA-N | |
COLLAPSE PRESSURE RATING:150 PSID | (C) INNER DIAMETER, TOP:1.27 IN (32.26 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:225 F | (D) INNER DIAMETER,BOTTOM:1.27 IN (32.26 MM) | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:20 PSID | (E) LENGTH:6.30 IN (32.26 MM) (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:N/A | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:DOUBLE OPEN END | |||
