Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 3.5 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Warranty Of Core Components: | 3 Month |
| Core Components: | Glass Fiber | Warranty: | 1 Year |
| Weight [kg]:: | 3.5 | I.a. Suitable For Series:: | Hydraulics |
| Outer Diameter [mm]:: | 143,5 | Height [mm]:: | 483 |
| Filter Medium:: | Glass Fibre | Innendurchmesser [mm]:: | 96,5 |
| Zul. Continuous Operating Temperature:: | -30°C Bis 100°C | Filter Fineness [μm]:: | 10 |
| Port: | Tianjin Qingdao Shanghai Ect |
Performance Data | Dimensional Specifications | Physical Specifications | |
MICRON RATING:12.00 ABSOLUTE | (A) OUTER DIAMETER, TOP:5.63 IN (143.00 MM) | Handle: YES | |
BETA RATING:B12=200 | (B) OUTER DIAMETER, BOTTOM:5.63 IN (143.00 MM) | Seal Material:VITON | |
COLLAPSE PRESSURE RATING:435 PSID | (C) INNER DIAMETER, TOP:3.75 IN (95.25 MM) | Type of Adhesive：EPOXY | |
MAXIMUM TEMPERATURE:275 F | (D) INNER DIAMETER,BOTTOM: | TYPE OF ENDCAP:PLATED STEEL | |
Direction of Flow: OUTSIDE->IN RECOMMENDED CHANGEOUT DIFFERENTIAL PRESSURE:50 PSID | (E) LENGTH:NONE (F) THREAD:NONE | CENTER TUBE:PLATED STEEL | |
Get the quote by contacting us | TYPE OF MEDIA:MICROGLASS | ||
FILTER AREA:SQ.IN. | |||
PLATING:ZINC PLATED | |||
OUTER JACKET:NONE | |||
CONFIGURATION:SINGLE OPEN END | |||
