Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
|---|---|---|---|
| Weight (KG): | 5.7 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 3 Months |
| Core Components: | Filter Paper | Warranty: | 1 Year |
| Weight [kg]: | 5.7 | Bottom Tie Rod Hole [mm]: | 23.62 |
| Filter Medium: | Cellulose |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 15.00 ABSOLUTE | (A) Outer Diameter, Top:14.75IN | Handle: YES | |
Beta Rating: N/A | (B) Outer Diameter, Bottom: 12.03IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 75 PSI | (C) Inner Diameter, Top: 0.90IN | Type of Adhesive:PLASTISOL | |
Maximum Temperature: 175 F | (D) Inner Diameter, Bottom: 7.68IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: 18.50 IN | Center Tube: PLATED STEEL | |
Get the quote by contacting us | Type of Media: PAPER | ||
Filter Area: SQ IN. | |||
Plating: ELECTROTIN PLATED | |||
Outer Jacket: YES | |||
Configuration: SINGLE OPEN END | |||
