Product Details:
|
| Applicable Industries: | Hotels, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Food Shop, Construction Works | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Paper Filter | Condition: | New |
| Efficiency: | 99.8% | Construction: | Cartridge Filter |
| Warranty: | 1 Year | Product Name: | Filter Cartridge |
| Filter Type: | Air Filter Cartridge | Function: | Clean Air |
| Micron: | 10 | Material: | Glass Fiber Filter Material |
| MOQ: | 1pcs | Brand: | BAMA |
| OEM: | Available | Service Life: | 5000h |
| After Warranty Service: | Video Technical Support, Online Support | Local Service Location: | None |
| Showroom Location: | None | Marketing Type: | Ordinary Product |
| After-sales Service Provided: | Online Support | Port: | Tianjin |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating: 0.50 99.99% | (A) Outer Diameter, Top: ** IN | Handle: NONE | |
Beta Rating: N/A | (B) Outer Diameter, Bottom: ** IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 75 PSI | (C) Inner Diameter, Top: ** IN | Type of Adhesive: PLASTISOL | |
Maximum Temperature: 180 F | (D) Inner Diameter, Bottom: ** | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length: ** IN | Center Tube: PLATED STEEL | |
Get the size by contacting us | Type of Media: NANOFIBER-FR | ||
Filter Area: 189 SQ.FT. | |||
Plating: ELECTRO-GALVANIZED | |||
Outer Jacket: YES - EXPANDED | |||
Configuration: DOUBLE OPEN END | |||
