Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Provided | Warranty Of Core Components: | 3 Months |
| Core Components: | Glass Fiber | Condition: | New |
| Construction: | Cartridge Filter | Dimension(L*W*H): | OEM |
| Weight: | 3 KG | Warranty: | 1 Year |
| Weight [kg]: | 3 | Area Of Application: | Hydraulics |
| Seals - Material: | NBR | Filter Medium: | Glasss Fiber |
| Max.differential Pressure [bar]:: | 10 | Filter Fineness [um(c)]: | B12=1000 |
| Permitted Continuous Use Temperature: | -25°C To +120°C |
Performance Data | Dimensional Specifications | Physical Specifications | |
Micron Rating10.00ABSOLUTE | (A) Outer Diameter, Top:5.94IN | Handle:NONE | |
Beta Rating: B10=200 | (B) Outer Diameter, Bottom: 5.94IN | Seal Material: BUNA-N | |
Collapse Pressure Rating: 225PSID | (C) Inner Diameter, Top:3.48IN | Type of Adhesive: EPOXY | |
Maximum Temperature:225F | (D) Inner Diameter, Bottom:3.48IN | Type of Endcap: PLATED STEEL | |
Direction of Flow: OUTSIDE->IN | (E) Length:15.74IN | Center Tube:PLATED STEEL | |
Get the quote by contacting us | Type of Media: MICROGLASS | ||
Filter Area:N/A | |||
Plating: ZINC PLATED | |||
Outer Jacket:NONE | |||
Configuration:DOUBLE OPEN END | |||
